Upgrading your bathroom with a new shower system can transform your daily routine into a spa-like experience. Whether you’re installing a rainfall showerhead, handheld sprayer, or a complete thermostatic shower system, the process might seem complicated, but with the right tools and guidance, it can be a manageable DIY project.
In this guide, Loraven will walk you through the step-by-step installation process, ensuring you set up your shower system efficiently and correctly.
Tools and Materials Needed
Before starting the installation, gather the following tools and materials:
✅ New Loraven shower system (rainfall showerhead, handheld sprayer, diverter valve, etc.)
✅ Adjustable wrench – For tightening and loosening fittings.
✅ Plumber’s tape – Helps prevent leaks at threaded connections.
✅ Screwdriver & drill – For securing brackets and hardware.
✅ Level – Ensures the shower components are aligned properly.
✅ Teflon tape – To seal threaded connections.
✅ Bucket or towel – To catch any excess water when removing old pipes.
Step-by-Step Installation Guide
Step 1: Turn Off the Water Supply
Before removing your old shower system, turn off the water supply at the main valve or shut-off valve. This prevents any accidental leaks or water damage.
💡 Loraven Tip: If you’re replacing an existing shower, open the old shower faucet to release any remaining water pressure.
Step 2: Remove the Old Showerhead and Fixtures
1. Unscrew the old showerhead by turning it counterclockwise with an adjustable wrench.
2. Remove any old brackets or shower arms if they are being replaced.
3. Clean the exposed pipe threads to remove any debris, rust, or old plumber’s tape.
💡 Loraven Tip: Wrap the shower arm with a towel before using a wrench to avoid scratching the finish.
Step 3: Install the New Shower Arm (If Required)
1. Apply plumber’s tape to the threaded end of the new shower arm.
2. Screw the shower arm into the wall fitting by hand, then tighten it slightly with a wrench.
3. Ensure the shower arm is level and pointing downward to prevent water leaks.
💡 Loraven Tip: If your shower system includes a rainfall showerhead, ensure the arm extends far enough for proper water flow.
Step 4: Install the Diverter Valve (If Applicable)
If your shower system includes a handheld sprayer, you will need to install a diverter valve to control the water flow between the showerhead and handheld sprayer.
1. Wrap plumber’s tape around the diverter’s threads.
2. Attach the diverter valve to the shower arm and tighten securely.
3. Connect the main showerhead to the diverter valve.
💡 Loraven Tip: Some diverter valves have additional water pressure settings—choose one that suits your preference.
Step 5: Attach the Showerhead and Handheld Sprayer
1. Install the main showerhead by screwing it onto the shower arm or diverter valve. Tighten it securely, but don’t overtighten.
2. Attach the handheld sprayer hose by connecting one end to the diverter valve and the other to the handheld showerhead.
3. Mount the handheld shower bracket at a convenient height using the included screws and anchors.
💡 Loraven Tip: If your system includes a rainfall showerhead, position it at least 7 feet above the ground for optimal coverage.
Step 6: Turn On the Water and Check for Leaks
1. Slowly turn the water supply back on and check for any leaks around the connections.
2. Test both the showerhead and handheld sprayer by switching between modes.
3. Tighten any leaking connections and ensure everything is properly aligned.
💡 Loraven Tip: If you notice low water pressure, ensure the flow restrictor hasn’t been left in place if you prefer stronger pressure.
Common Installation Mistakes to Avoid
🚫 Skipping the plumber’s tape – Always wrap Teflon tape around threaded connections to prevent leaks.
🚫 Overtightening connections – This can cause cracks in fittings or lead to difficult removal later.
🚫 Ignoring proper height adjustments – Ensure the showerhead is positioned for comfortable use, especially for taller users.
🚫 Not testing before sealing components – Before finalizing the installation, always turn on the water to check for potential issues.
Why Choose a Loraven Shower System?
At Loraven, we offer high-quality shower systems designed for comfort, durability, and modern aesthetics. Whether you prefer a luxurious rainfall shower, a high-pressure handheld sprayer, or an all-in-one thermostatic system, we have the perfect solution for your bathroom.
✔ Premium Materials – Made from solid brass and stainless steel for longevity.
✔ Easy DIY Installation – Designed for quick and hassle-free setup.
✔ Multiple Water Modes – Enjoy different spray settings, from soft mist to powerful jet streams.
✔ Modern Design – Available in brushed nickel, matte black, and chrome finishes to suit any bathroom style.
Final Thoughts
Installing a new shower system is a rewarding upgrade that enhances both the functionality and style of your bathroom. By following these simple steps, you can enjoy a spa-like shower experience with Loraven’s premium shower systems.
Ready to upgrade your bathroom? Explore Loraven’s collection of elegant and high-performance shower systems today!
